CRRC Times Semiconductor KK1800A/1800V Fast Switching Thyristor (SCR)
The CRRC Times Semiconductor KK1800A/1800V is a premium-grade, disc-type (capsule/puck) fast switching thyristor engineered for high-power industrial applications. Manufactured by the industry-leading Zhuzhou CRRC Times Semiconductor Co., Ltd., this robust Silicon Controlled Rectifier (SCR) delivers exceptional reliability and efficiency in power conversion, motor control, and induction heating systems. It features a high average on-state current of 1800A and a repetitive peak voltage rating of 1800V, ensuring optimal performance under demanding electrical loads. With a rapid turn-off time of 330 μs and high critical rates of rise for both current (di/dt ≥1000 A/μs) and voltage (dv/dt ≥1000 V/μs), the KK1800A/1800V guarantees precise control and superior dynamic characteristics in high-frequency switching environments.
Technical Specifications:
- Brand: CRRC Times Semiconductor
- Model: KK1800A/1800V
- Device Type: Disc-type (Capsule/Puck) Fast Switching Thyristor (SCR)
- Average On-State Current (IT(AV)): 1800 A
- Peak On-State Current (ITM): 3000 A
- Repetitive Peak Voltage (VDRM/VRRM): 1800 V
- On-State Peak Voltage (VTM): 1.92 V
- Repetitive Peak Off-State Current (IDRM): 31 mA
- Repetitive Peak Reverse Current (IRRM): 35 mA
- Gate Trigger Current (IGT): 114 mA
- Gate Trigger Voltage (VGT): 1.28 V
- Turn-Off Time (tq): 330 μs
- Recovered Charge (Qrr): 670 μC
- Critical Rate of Rise of On-State Current (di/dt): ≥1000 A/μs (Tc=55 ℃)
- Critical Rate of Rise of Off-State Voltage (dv/dt): ≥1000 V/μs
- Manufacturer: Zhuzhou CRRC Times Semiconductor Co., Ltd.
| Brand | CRRC Times Semiconductor |
|---|---|
| Model | KK1800A/1800V |
