Rexroth 4WEH 16 J72/6HG24N9ETK4/B10 Electro-hydraulic Directional Control Valve
Buy the genuine Rexroth 4WEH 16 J72/6HG24N9ETK4/B10 (R901108808) electro-hydraulic directional valve. This NG16, 4/3-way valve features a J-spool, 24V DC solenoids, and manual override for precise hydraulic control.
Payment Methods:
-
Online Support 24/7
-
12 Months Warranty for New Products
-
30 Days Money Back Guarantee
Rexroth 4WEH 16 J72/6HG24N9ETK4/B10 Electro-hydraulic Directional Control Valve
The Rexroth 4WEH 16 J72/6HG24N9ETK4/B10 is a high-performance, electro-hydraulically operated directional spool valve designed for reliable control of fluid flow in hydraulic systems. This valve is used to start, stop, and direct the flow of hydraulic fluid, enabling precise control over actuators like cylinders and motors. It features a robust design with a size 16 mounting pattern (NG16, CETOP 07), spring-centered J-spool, and operates on a 24V DC electrical supply. The integrated manual override allows for valve operation during power outages or for setup purposes. This model also includes a throttle insert for controlled switching times, making it ideal for demanding industrial and mobile hydraulic applications.
Technical Specifications:
- Model: 4WEH 16 J72/6HG24N9ETK4/B10
- Material Number (MNR): R901108808
- Valve Type: 4/3-way Electro-hydraulic Directional Spool Valve
- Nominal Size: 16 (NG16 / CETOP 07)
- Spool Symbol: J
- Actuation: Electro-hydraulic with 24V DC solenoids
- Max. Operating Pressure: Ports P, A, B: 350 bar | Port T: 210 bar
- Max. Flow Rate: 300 l/min
- Features: Concealed manual override (ET), Throttle insert Ø 1.0 mm (B10)
| Brand | Rexroth |
|---|---|
| Model | 4WEH 16 J72/6HG24N9ETK4/B10 |
