TURCK TP-1-06A-G1/8-H1141-L200 Temperature Sensor
Purchase the TURCK TP-1-06A-G1/8-H1141-L200 (Ident-No. 6840015) industrial Pt100 temperature sensor. Features a -50 to +150 °C range, 200mm probe, G1/8″ thread, and M12 connector. Ideal for reliable temperature monitoring in industrial automation.
Payment Methods:
-
Online Support 24/7
-
12 Months Warranty for New Products
-
30 Days Money Back Guarantee
TURCK TP-1-06A-G1/8-H1141-L200 Temperature Sensor
The TURCK TP-1-06A-G1/8-H1141-L200 is a high-precision industrial temperature sensor designed for reliable and accurate measurements in demanding automation environments. Manufactured in Germany, this sensor features a robust stainless steel (1.4571/AISI 316Ti) housing and a Pt100 measuring element, ensuring excellent durability and stable performance across a wide temperature range. With a standard G1/8″ male thread process connection and a 200 mm probe length, it offers straightforward installation in various industrial applications, including machine building, process control, and HVAC systems. The integrated M12 connector provides a secure and standardized electrical connection, protected to an IP67 rating for resistance against dust and water ingress.
Technical Specifications:
- Model: TP-1-06A-G1/8-H1141-L200
- Identification Number: 6840015
- Measuring Principle: Pt100 resistance thermometer (Class A acc. to IEC 60751)
- Measuring Range: -50 to +150 °C (-58 to +302 °F)
- Process Connection: Male thread G 1/8″
- Probe/Immersion Length (L): 200 mm
- Housing Material: Stainless steel, 1.4571 (AISI 316Ti)
- Electrical Connection: M12 x 1 Connector, 4-pin
- Protection Class: IP67
| Brand | Turck |
|---|---|
| Model | TP-1-06A-G1/8-H1141-L200 |
